Flow meters and transmitters

The Foxboro CFS10 and CFS20 mass flow tubes form a Coriolis mass flow measurement together with the CFT51 series Coriolis transmitter. The principle of Coriolis acceleration is used, with which real mass flow measurements of liquids can be carried out directly, without the need for a separate temperature, pressure or density meter. The CFS10 has a single flow tube and is available in diameters...

The CFS25 mass flow tubes can be combined with a CFT51 Coriolis flow transmitter to form a Coriolis mass flow and density meter. The principle of Coriolis acceleration is used, with which real mass flow measurements of liquids can be carried out directly, without requiring external temperature, pressure or density measurements. The CFS25 series consists of flow tubes with a double pad. The liqu...

De Schneider Electric IMT30A is een flowtransmitter voor gebruikt met magnetische flowbuizen,zoals de 8400A, 8500A, 9500A, 9600A en 9700A serie. De IMT30A vormt het signaal van een magnetische flowbuis om naar een 4-20mA, Hart, Modbus of pulse-uitgang. De IMT30A is geschikt voor veilige zones en kan worden geleverd met of zonder display.

De Schneider Electric IMT31A is een flowtransmitter voor gebruikt met magnetische flowbuizen,zoals de 8400A, 8500A, 9500A, 9600A en 9700A serie. De IMT31A vormt het signaal van een magnetische flowbuis om naar een 4-20mA, Hart, Modbus, Foundation Fieldbus, of Profibus PA en DP. De IMT31A is geschikt voor explosieveilige zones (Ex i) als deze wordt gecombineerd met de 9500A of 96700A flowbuizen.

De Schneider Electric IMT33A is een explosieveilige flowtransmitter voor gebruikt met de 9500A, 9600A en 9700A serie magnetische flowbuizen. De IMT33A vormt het signaal van een magnetische flowbuis om naar een 4-20mA, Hart, Modbus, puls of Foundation Fieldbus. De IMT33A is geschikt voor explosieveilige zones (Ex d) volgens ATEX, IECex, FM en CSA.

The CFS400A has been developed to meet the demanding custody transfer requirements of the oil and gas industry and is well suited to bulk measurement in many applications. The option of Super Duplex (UNS S32760) provides a maximum operating pressure of 180 barg. A high level of performance makes the CFS400A suitable for the bulk measurement of petroleum and oil as well as products like syrup, m...

The Rate-Master® flowmeter line of direct reading precision flowmeters incorporates many unique user features at moderate cost. These low cost flowmeters are ideal for general use.

Max Machinery P001 Series Piston Flow Meters work on the positive displacement principle. This principle measures flow based on a fixed amount of pistons, which measure these flowmeters very accurately. The P001 is designed for a very low flow of 0.005 ml per minute. The piston flow meters are suitable for hydrocarbon based liquids and can exhibit very high pressures and temperatures.

The FineTek EPD30 electromagnetic flowmeter offers industry a wide range of designs to meet even the most demanding process applications in diverse sectors such as chemistry, energy, oil and gas, metal and mining. The powerful transmitter is easy to use and delivers the output signal that meets your needs. EPD30 offers a versatile, reasonably priced, accurate flowmeter for your applications. Th...

The Dwyer IEF series electromagnetic flow transmitter is an adjustable flow meter with electromagnetic technology that accurately and reliably measures a fluid velocity. The IEF series is specifically designed to deliver superior performance in combination with easy installation and use. The IEF flow meter is adjustable for pipe sizes from 100 to 900 mm and offers various output signals, includ...

The Foxboro CFT51 series digital Coriolis Mass Flow and Density Transmitter is an improvement of the CFT50 flow meters that introduced a completely new technology in the field of coriolis flow measurement. In combination with a Foxboro CFS10 or CFS20 flow tubes, the CFT51 series forms a mass flow and density meter. The digital signal processing (DSP) offers improved flowmeter performance and ad...

The 8600MP and 8700MP series from Eldridge consists of thermal mass flowmeters for gases. This inline version contains a piece of straight pipe in which the thermal mass flow sensor is included. The pipe diameter can be selected so that it matches the existing process pipe. The flow transmitter is mounted directly on the housing and has an integrated display. The 8600MP and 8700MP mass flowmete...

The 8800MP series from Eldridge consists of thermal mass flowmeters for gases. This insertion version can be installed in a socket, independent of the pipe diameter. This makes installation easy, even in an existing process piping. The flow transmitter is mounted directly on the housing and has an integrated display. The 8800MP mass flowmeters are explosion-proof according to ATEX, IECex, CSA a...

The Foxboro® 84F series consists of intelligent, high-performance vortex flow meters with flange or NPT connections. The flow meters have standard pulse and a 4-20 mA output with Hart communication. A built-in LCD display with pushbuttons is offered for local configuration of the 84F series. No other vortex flow meter is as accurate in the field of liquid, gas and steam flow measurements at tem...

The 84CF series vortex mass flowmeter complements the Foxboro family of intelligent, powerful vortex flowmeters. The 84CF series is available with 4 to 20 mA, HART® 7 and pulse output and is equipped with temperature compensation for mass flow measurement of saturated steam (saturated steam) and liquids. In addition, the Foxboro 84CF has the patented Active Tuning technology that significantly...

The TM10 is a wireless transmitter for turbine flowmeters (not included). The Accutech TM10 converts the pulse output of a turbine flowmeter into a current flow rate and also registers the total flow. The values from the wireless Accutech transmitters can be transmitted over distances of up to 1000 meters in open field conditions. The TM10 transmitter features a rugged explosion-proof housin...

The MF3000 flow meter for solids is designed for flow measurement in metal tubes from a few kg / hour to many tons / hour. The system is suitable for flow measurements of powders, granulates and granules from 1 nm to 2 cm in pneumatic or free-fall conditions. The measuring principle of the MF 3000 is based on the doppler effect, where microwaves are reflected by particles passing through the tu...

The Schneider Electric 8400A magnetic flow tube, in combination with the IMT series transmitters, forms an economical flow meter with wafer connection. The 8400A magnetic flow meters are available in sizes from DN10 to DN150 for light industrial applications at a competitive price. For higher accuracy and chemical resistance, we recommend the 8500A series.

The Schneider Electric 8500A magnetic flow tube, in combination with the IMT series transmitters, forms a robust and reliable flow meter with a wafer connection. The 8500A magnetic flow meters are available in sizes from DN2.5 to DN100 for industrial applications requiring high accuracy. Various lining and electrode materials are available to ensure optimal chemical resistance.

The Schneider electric 9500A series magnetic flow tube together with the IMT series transmitters form a reliable and universal flow meter with flange connection. The 9500A magnetic flow meters are available in sizes from DN25 to DN2000 suitable for drinking water, wastewater and light industrial applications. The 9500A series can also be used as a bidirectional flow meter. We recommend the 9700...

The Schneider Electric 9700A magnetic flow tube, in combination with the IMT series transmitters, forms a flow meter for chemical applications with a flanged connection. The 9700A magnetic flow meters are available in sizes from DN10 to DN2000 and are suitable for chemical and heavy industrial applications. Various lining and electrode materials are available to ensure optimal chemical resis...

The 84CW series vortex mass flow meter with wafer connection is an addition to the Schneider Electric (formerly Foxboro) family of intelligent, high-performance vortex flow meters. The 84CW series is available with 4 to 20 mA, HART7, and/or Modbus communication and can optionally be equipped with temperature compensation for mass flow measurement of saturated steam and liquids. Additionally,...

The 84CN series vortex mass flow meter with threaded connection complements Schneider Electric (formerly Foxboro) family of intelligent, powerful vortex flowmeters. The 84CN series is available with 4 to 20 mA, HART7 and or Modbus communication and can optionally be equipped with temperature compensation for mass flow measurement of saturated steam and liquids. In addition, the Foxboro 84CN fea...

The 84CS series vortex mass flow meter with sanitary connection for the pharmaceutical and food industries is an addition to the Schneider Electric (formerly Foxboro) family of intelligent, high-performance vortex flow meters. The 84CS series is available with 4 to 20 mA, HART7, and/or Modbus communication and can optionally be equipped with temperature com...

The CFS300A is the cost effective solution for accurate measurement for a variety of applications. The CFS300A reliably measures mass, density, volume, temperature, volume concentration or solid content. Dual-straight tube with optimized flow splitter, for general purpose applications and process control. End connections available for ½” (DN15) to 4” (DN100).

The CFS700A is the only sensor for mass flow with a single straight measuring tube that is available in Titanium, Stainless Steel, Hastelloy® or Tantalum. Single straight tube without flow splitter for lowest pressure drop, for advanced applications and harsh environments. End connections available for ½” (DN15) to 4” (DN100).

The CFT34A Coriolis mass flow transmitter will provide the highest performance possible across a wide range of applications. For the measurement of liquids or gases, cryogenic to high temperature fluids, single or multi-phase fluids and advanced digital signal processing techniques is used to give accurate measurements of mass flow, density and temperature. It is developed according to IEC 615...

The Schneider electric 6500W series is a battery-powered magnetic flow meter. This water meter has been developed for drinking water applications in remote locations where mains power is not available. Of course it is also suitable for other applications where battery power is useful. For locations with mains voltage, there is the FlexPower unit, with which the 6500W can also be connected to 23...

The 9600A series of magnetic flowmeters have been specially developed for use in the pharmaceutical and food industry. The 9600A series flowmeters are 3A, FDA and EHEDG certified for hygienic application, as well as ATEX, FM and CSA for explosion-proof application. The magnetic flow meters can communicate via Hart, Foundation Fieldbus or Modbus. Versions are available for pipe diameters from 2....

The Dwyer Flow Meter Series VF Visi-Float is a compact and reliable solution, ideal for measuring air, water, and other compatible liquids or gases. Made from high-quality acrylic and featuring a robust construction, the Visi-Float offers excellent durability and accuracy, even in demanding applications.
