Barksdale pressure switch series D1T-D2T

Artikel

Model

Bereik / omschrijving

Prijs

2004934

D1T-H2SS

Range: 0,005 to 0,11 bar, 1 x SPDT

2012231

D1T-H3SS

Range: 0,012 to 0,2 bar, 1 x SPDT

2005177

D1T-H18SS

Range 0,05 to 1,2 bar, 1 x SPDT

2010929

D1T-H80SS

Range 0,3 to 5,5 bar, 1 x SPDT

2010406

D1T-H150SS

Range: 0,52 to 10 bar, 1 x SPDT

2017081

D2T-H2SS

Range: 0,005 to 0,11 bar, 2 x SPDT

2017082

D2T-H3SS

Range: 0,012 to 0,2 bar, 2 x SPDT

2004937

D2T-H18SS

Range: 0,05 to 1,2 bar, 2 x SPDT

2016579

D2T-H80SS

Range: 0,3 to 5,5 bar, 2 x SPDT

2006977

D2T-H150SS

Range: 0,5 to 10,3 bar, 2 x SPDT

Metal diaphragm pressure switches with direct-acting pressure sensor and the snap-acting micro switch provide very high accuracy and long life span. Main features are that the wetted parts are welded, direct acting, no friction and high accuracy. Available with 1 (D1T) or 2 (D2T)setpoints. Measuring ranges from -0.006 ... -1 bar up to 0.005 ... 10.3 bar. Main applications are petrochemicals industry, process technology, shipbuilding technology,

Medium	Compatible gases Compatible liquids
Contact	SPDT SPDT (2x)
Process connection	1/4" NPTf
Certifications	Atex Ex i (optional)
Housing	IP65
Measuring principle	Diaphragm
Power supply	Not applicable
Range - pressure	< 1000 mbar < 10 bar < 0 bar (vaccuum)
