These inexpensive manometers measure positive, negative and differential pressures. Dwyer Flex-Tube U-Tube Manometers combine the inherent accuracy of the simple "U" Tube with the durability of tough, long-lasting plastic construction. Series 1221 Manometer, the simplest, lowest cost basic U-gage. Series 1222 Manometer, alll the features of the 1221 plus magnetic clips. Series 1223 Manometer, t...

Dwyer pitot tubes, series 160 are constructed from corrosion resistant stainless steel for a lifetime of service. No correction factors or calibration required. Various standard sizes are available for use in small and large ducts.

Model 1950 explosion proof pressure pressure switch combines the best features of the popular1900 series with an integral explosion-proof and weatherproof housing, making it an exceptional value for either application. It is CE, UL and CSA listed, FM approved for use in Class I, Div 1, Groups C and D, Class II Groups E, F, and G and Class III hazardous atmospheres (NEMA 7 & 9), Raintight NEMA 3...

The Model 1950G Explosion-Proof Switch combines the best features of the popular Dwyer® Series 1950 Pressure Switch with the benefit of natural gas compatibility. Units are rain-tight for outdoor installations, And are ATEX approved CE ATEX II 2G Exd IIB+H2 T6. Adjustment to the set point of the switch can be made without disassembly of the housing.

Dwyer Magnehelic gage for high accuracy, guaranteed within 2% of full scale and for the wide choice of 81 models available to suit your needs precisely. Using Dwyer's simple, frictionless Magnehelic gage movement, it quickly indicates low air or noncorrosive gas pressures, either positive, negative (vacuum) or differential. The design resists shock, vibration and over-pressures. No manometer fl...

The Minihelic is a small differential pressure manometer, suitable for many of the same applications as the Magnehelic gage where the greater accuracy, sensitivity, and higher and lower differential pressure ranges of the Magnehelic gage are not required. It can safely operate at total pressures up to 200 kPa. With the housing molded from mineral and glass filled nylon and the lens molded from...

The series 3000MR Photohelic switch/gages combine the functions of a precise, highly repeatable differential pressure switch with a large easy-to-read analog pressure gage employing the durable, time-proven Magnehelic gage design. The Photohelic has 2 switch functions. Switch setting is easy to adjust with large external knobs on the gage face. Gage reading is unaffected by switch operation — w...

The Capsuhelic gage is designed to give fast, accurate indication of differential pressures. The gage may be used as a readout device when measuring flowing fluids, pressure drop across filters, liquid levels in storage tanks and many other applications involving pressure, vacuum or differential pressure.

Model 485B is a compact, hand-held instrument for measuring percentage of relative humidiy and temperature in °C or °F and also calculates dew point and wet bulb temperature. It will store up to 99 readings, ideal for technicians meeding to take multiple readings for later analyses.

The Model AAFS air flow switch provides excellent sensitivity and reliability at a very reasonable price. Quality features include a rugged die cast body, stainless steel vane and SPDT snap switch. Unit is field adjustable from 400-1600 FPM. Mounting is fast and simple,with only two screws needed. Vane fits 6 inch or larger ducts.

The Series 629C Differential Pressure Transmitter monitors differential pressure of air and compatible gases and liquids with 0.5% accuracy. The design employs dual pressure sensors converting pressure changes into a standard 4-20 mA output signal for two wire circuits. Small internal volume and minimum moving parts result in exceptional response and reliability.

Serves as pressure source to calibrate gages and transmitters or to set pressure switches. Use with manometer or other pressure standard. Generate pressures from a fraction of an inch w.c. to 72 psig (5 bar). Includes barbed fitting, tee connector and three 36? lengths of vinyl tubing.

The Series ADPS Adjustable Differential Pressure Switch is designed for pressure, vacuum, and differential pressures. The adjustment knob allows changes to the switching pressure to be made without a pressure gage. The ADPS is available with settings from 20 Pa up to 5000 Pa. The compact size, adjustment knob and low cost make the ADPS the perfect choice for HVAC applications.

The Dwyer series DM-2000 differential pressure transmitter senses the pressure of air and compatible gases and sends a standard 4-20 mA output signal. The DM-2000 housing is specifically designed to mount in the same diameter cutout as a standard Magnehelic gage. A wide range of models are available factory calibrated to specific ranges. Pressure connections are inherent to the glass filled pla...

The Series DPG has a high ±0.25% full scale accuracy. The 4 digit digital display will reduce the potential for errors in readings by eliminating parallax error commonly produced with analog gages. Series DPG is battery powered and has an auto-shut off to conserve battery life. Battery life, on average, will last 2000 hours. A 4 button key pad allows easy access to features without the need to...

The Series DPG-200 digital pressure gage has a precise ±0.25% full scale accuracy. The 4 digit digital display will reduce the potential for errors in readings by eliminating parallax error commonly produced with analog gages. The DPG-200 is packaged in a durable extruded aluminum case (IP66). The unit is powered by 12-24 VDC/VAC and contains two alarm set points along with a 4-20 mA process ou...

The series DPGA is the only economic digital pressure gage with selectable engineering units on the market. With its 1% accuracy and digital push-button zero, the DPGA is the perfect choice for digitally monitoring the pressures of air and compatible gases.

The Series DPGW is the only economic digital pressure gage for liquids with the ability to select engineering units on the market. With its 1% accuracy and digital push-button zero, the DPGW is the perfect choice for digitally monitoring the pressures of compatible liquids and gases. The 4 digit digital display will reduce the potential for errors in readings by eliminating parallax error commo...

Explosion-proof, heavy duty, industrial pressure switch which provides sensitivity to differential pressure as low as 25 mbar up to 14 bar with a max. static pressure of 100 bar. This unit has a standard aluminium pressure chamber but is also available in 316 stainless steel. Approvals : UL, CSA, CE and ATEX.

Rugged and reliable the Series L4 Flotect Level switch operates automatically to indicate tank level. Perfect for starting or stopping pumps, opening or closing valves, or actuate level alarm signals. Horizontal installation or optional top mount vertical installation. ATEX version available.

Model L8 Flotect Liquid Level Switch features a leak proof body and float constructed from tough, durable polyphenylene sulfide which has excellent chemical resistance. This compact and reliable control is designed to handle temperatures up to (100°C and pressures to 10 bar.

Dwyer Mark II series molded manometers are of the inclined and inclined-vertical types. The curved inclined-vertical tube of the Mark II manometers can be mounted on any vertical surface with the two mounting screws provided. Ranges available from 0-80 mmH2O and from -10 to + 700 Pa.

The MP Mini-Photohelic differential pressure switch/gage combines the time proven Minihelic II differential pressure gage with two SPDT switching setpoints. The Mini-Photohelic gage is designed to measure and control positive, negative, or differential pressures consisting of non-combustible and non-corrosive gases. Gage reading is independent of switch operation. This extremely compact switch...

The Series MS Magnesense Differential Pressure Transmitter is an extremely versatile transmitter for monitoring pressure and air velocity. This compact package is loaded with features such as: field selectable english or metric ranges, field upgradeable LCD display, adjustable dampening of output signal (with optional display) and ability to select a square root output for use with pitot tubes...
