Differential pressure transmitters

The Micaflex MF-P / MF-PD is a differential pressure transmitter for measuring positive pressure, negative pressure or differential pressure, with or without a display.

The MF-PFA series can measure the airflow in combination with the self-averaging MFS flow sensors in addition to differential pressure. Besides analog outputs, this series also features a built-in PI controller, which can directly controll a fan and 2 swithes for local alarms. Due to the high accuracy and stability, the MF-PFA is ideal for use in laboratories, hospitals and clean rooms. Each in...

In addition to differential pressure, the MF-PFC transmitter also measures air velocities in combination with the MFS self-averaging flow sensors. The transmitter has 2 analog outputs that can be used for differential pressure, flow or PI control output. For example, the control output can be used to directly control a VAV valve. High accuracy and stability make the MF-PFC ideal for use in labo...

The Foxboro IDP10 series is a compact and robust differential pressure transmitter for direct process mounting. The IDP10 series is available in different measuring ranges of 75 mbar, 500 mbar, 2.1 bar, 21 bar and 210 bar differential pressure. As signal output you can choose 1-5V, 4-20 mA, Hart, Foudation Fielbus and FoxCom. The IDP10 series can be designed as a differential pressure transmitt...

The Foxboro Accutech series includes these wireless differential pressure transmitters. The DP20 is a wireless differential pressure transmitter with ranges up to +/- 300in H20 (+/- 762mm H2O). The Accutech transmitters communicate with the Accutech base station over distances up to 48 km.

The IDP05S series is a budget-friendly differential pressure transmitter within the Schneider Electric range with standard SIL2 certification. The IDP05S measures a pressure difference with an accuracy of 0.075% of the chosen measuring range, ranging from 50 kPa to 207 bar. This makes the IDP05S differential pressure transmitter less accurate than its bigger brothers, but also a lot cheaper. Fo...

The IDP10S series is a very robust and advanced differential pressure transmitter within the Schneider Electric range and is SIL2 certified as standard. The IDP10S measures a pressure difference with an accuracy of 0.05% of the reading. Thanks to the special FoxCal technology, one transmitter has no less than 11 calibration curves in a pressure range of 0-414 bar. This allows the same model of...

The IDP50S series is a very robust and extremely accurate differential pressure transmitter within the Schneider Electric range and is SIL2 certified as standard. The IDP50S measures a pressure difference with an accuracy of 0.025% of the reading. Thanks to the special FoxCal technology, one transmitter has no less than 11 calibration curves in a pressure range of 0-414 bar. This allows the sam...

The wireless WDP10 differential pressure sensors measure the differential pressure of various industrial processes and transmit them wirelessly to a central collector (WCC10). This sends the values from multiple sensors via WirelessHART to any central system. There are versions with differential pressure ranges up to 500 mbar, 2.1 bar or 21 bar. The field sensors are explosion-proof according t...

The Barksdale BDS3000 series is an electronic differential pressure switch, designed for monitoring (hydraulic) filter systems. There are versions with one or two switching contacts, but also with an analog output, so that it can be used as a differential pressure transmitter. There are different measurement ranges from 350 mbar to 35 bar. The BDS3000 is suitable as filter monitoring, but can a...

In addition to differential pressure, the MF-PFTT series transmitter also measures air velocities in combination with the MFS self-averaging flow sensors. Complementing its brother MF-PFT, the MF-PFTT has a temperature input for active temperature compensation. This is a very useful addition, especially with process air that varies a lot in temperature. This input is passive (Pt-100/1000) or ac...

The Foxboro® brand Models 15A, 13A, and 13HA pneumatic d/p Cell transmitters measure differential pressure and transmit a standard pneumatic signal to receivers which may be several hundred metres or yards away. Foxboro d/p Cell Transmitters have been the standard of process industry ever since they were developed and introduced for sale more than 30 years ago. Many thousands of successful, tro...

The Series 629C Differential Pressure Transmitter monitors differential pressure of air and compatible gases and liquids with 0.5% accuracy. The design employs dual pressure sensors converting pressure changes into a standard 4-20 mA output signal for two wire circuits. Small internal volume and minimum moving parts result in exceptional response and reliability.

The Dwyer series DM-2000 differential pressure transmitter senses the pressure of air and compatible gases and sends a standard 4-20 mA output signal. The DM-2000 housing is specifically designed to mount in the same diameter cutout as a standard Magnehelic gage. A wide range of models are available factory calibrated to specific ranges. Pressure connections are inherent to the glass filled pla...

The Series MS Magnesense Differential Pressure Transmitter is an extremely versatile transmitter for monitoring pressure and air velocity. This compact package is loaded with features such as: field selectable english or metric ranges, field upgradeable LCD display, adjustable dampening of output signal (with optional display) and ability to select a square root output for use with pitot tubes...

The ATEX-certified AT2MS series Magnesense® differential pressure transmitter is an extremely versatile transmitter for monitoring pressure and air velocity in potentially hazardous areas. The AT2MS transmitter can be set up in English or metric ranges and can be extended with an LCD screen. A square root output can be set for use with pitot tubes and similar flow sensors. The flameproof ATEX h...

The ATEX certified AT2DH3 series Digihelic® differential pressure controller is a 3-in-1 instrument that consists of a digital differential pressure gauge, relay contacts for alarms, or on-off control and a transmitter output. The AT2DH3 can also be used to measure air velocities and flow in combination with a pitot tube. The AT2DH3 has an analogue 4-20 mA output and two SPDT relay contacts wit...

The Dwyer Magnesense Series MSX Pro differential pressure transmitter is the professional differential pressure transmitter that meets rigorous industry standards with innovative product design. The instrument has exceptional stability for use in critical building applications with the versatility of our original series Magnesense transmitters. Pressure ranges in Pa, mmH2O, and inWC are availab...

The Kimo CP110 series is a differential pressure transmitter with or without display. The CP114 and CP115 are ideal for filter monitoring applications with an analog output to a building management system. The installation is very easy and the housing can be mounted in two parts making it ideal for installers.

The Kimo CPE310 differential pressure transmitter is the successor of the CPE300. The transmitter can be flush mounted in a wall and can be calibrated using special connectors from the front. The CPE310 has an internal buzzer with acceptance and delay. Optionally, an external sensor for temperature and humidity, can be connected, the display then scrolls between the values​​. The CPE310-S has 3...

The Dwyer RSMC Room Status Monitor Series is designed for critical applications with low differential pressures that also require immediate local visibility. The 4.3” full color touchscreen can be configured to measure positive or negative pressure in, for example, cleanrooms, hospitals, isolation rooms and laboratories. The Dwyer RSME Room Status Monitor is a complete solution with a touchscre...

The Series 605 Magnehelic Indicating Transmitter provides for both visual monitoring and electronic control of very low differential pressure. The Series 605 is ideal for control applications in building HVAC systems The easily read dial gage is complimented by the two-wire, 4-20 mA control signal utilizing the timeproven Dwyer® Magnehelic® gage mechanical design and Series 600 transmitter tech...

Micaflex MF-P / MF-PD is a pressure transmitter designed for low positive, negative and differential pressure in air-handling and ventilation systems where low pressure measuring is needed. They have an adjustable damping and a choice between a 0-10 V or 4-20 mA output. All transmitters can be delivered with or without a LCD display.

The MF-PFT series can measure the airflow in combination with the self-averaging MFS flow sensors in addition to differential pressure. Besides analog outputs, this series also features a built-in PI controller, which can directly controll a fan. Due to the high accuracy and stability, the MF-PFT is ideal for use in laboratories, hospitals and clean rooms. Each instrument is fully programmable.
