Wireless systems

With the WCC10 central collector from Schneider Electric, the data from 8 wireless IAN field sensors can be collected. There are field sensors for measuring temperature, pressure and differential pressure. Communication between the field sensors and the WCC10 is via Bluetooth and can be fully configured with an app via WiFi. This makes the system very flexible and very easy to install. In addit...

The LoRa SPY data recorders use the public LoraWAN network, which has national coverage in the Netherlands via provider KPN. Due to the strong LoRa signal it is possible to place the loggers almost everywhere, even in fridges with the door closed. The local display on the logger shows the last measured value and the recorders send their data directly to the MySirius software in the cloud via th...

The JRI MySirius application allows fully customizable management thanks to a dashboard and modules adapted to needs and jobs of the users. The data transmitted by the LoRa® SPY connected temperature sensors are easily overseen and managed on - full-web platform. The interface is user-friendly, intuitive and customizable with different indicators and favorites offering a data management adap...

The wireless WDP10 differential pressure sensors measure the differential pressure of various industrial processes and transmit them wirelessly to a central collector (WCC10). This sends the values from multiple sensors via WirelessHART to any central system. There are versions with differential pressure ranges up to 500 mbar, 2.1 bar or 21 bar. The field sensors are explosion-proof according t...

The wireless WGP10 relative pressure sensors measure the pressure of various industrial processes and transmit them wirelessly to a central collector (WCC10). This sends the values from multiple sensors via WirelessHART to any central system. There are versions with pressure ranges up to 2.1, 21 or 70 bar. The field sensors are explosion-proof according to ATEX and Canadian and American guideli...

The wireless WAP10 absolute pressure sensors measure the pressure of various industrial processes and transmit them wirelessly to a central collector (WCC10). This sends the values from multiple sensors via WirelessHART to any central system. There are versions with pressure ranges up to 2.1 bar absolute. The field sensors are explosion-proof according to ATEX and Canadian and American guidelines.

The wireless WRT10 temperature sensors measure the temperature of various industrial processes and send them wirelessly to a central collector (WCC10). This sends the values from multiple sensors via WirelessHART to any central system. There are RTD and thermocouple versions from -200 to + 885 ° C with various insertion lengths between 50 and 400 mm. Optionally, thermowells in various lengths c...
